FAST
FACTS
- With peak power occurring @ 7900 RPM and paired with a 3.62 axle ratio, the drivetrain practically begs the driver not to shift until the 8,000 RPM redline. It was obvious how proud BMW was of the S54, as it produced the highest specific output of any naturally aspirated engine in BMW’s history (minus the limited production V12 developed for the McLaren F1)
- The piece de resistance is a set of 6 motorsport-inspired DBW individual throttle bodies that provide the required airflow for an 8,000 RPM redline. During development, however, BMW had difficulty fitting this intricate intake setup underneath the hood of the standard 3 series. Their solution was to create a sporty-looking bulge in the center of the hood to accommodate the intake. This bulge is commonly referred to as the “Power Dome”
- It was also realized during development that the side fender vents (which were intended to evacuate heat from the engine bay) weren’t very effective. However, the design was already approved by the management team, and since everyone liked the added design touch, BMW decided to keep them. These tiny vents stayed put as a signature design trait of all BMW M cars moving forward
- In an unconventional attempt to provide increased steering feel for the driver, the M3’s rack and pinion steering employs a slower steering ratio than the base 3 series (15.4:1 on the M3 vs 13.7:1 on base cars). However, the ratio might have been too slow, as BMW found the need to upgrade to a faster ratio (14.5:1) for buyers who opted for the driver-focused Competition package (offered in ’05 and ’06)
- BMW’s M division was highly against the idea of putting an automatic transmission in the E46 M3. The development team must have put up quite a fight against corporate because, in the end, they got what they wanted – no automatic transmission was to be offered in the M3, despite the push from corporate. The car was to be built exclusively with one transmission: a 6spd manual. There was one caveat: buyers could opt to have the transmission electronically controlled, without a clutch pedal. This computerized setup, referred to as SMG (Sequential Manual Gearbox), was as close as buyers could get to an automatic trans. The computer (Drive Logic) engages the clutch during gear changes, and you can control the speed (and aggressiveness) of the shift via 6 selectable settings
- Using only one transmission for all cars not only saved BMW money, but it made it extremely easy to convert an SMG car to a gated 6spd
- Because they are the same transmission, an SMG car will put down the same power as the manual car (no extra drivetrain loss found in traditional automatics). This makes “manual” swapping an M3 much easier than any other car, as the transmission and driveshaft are already in place. The swap mainly involves removing the SMG components (which weigh only 18lbs), adding a 3rd pedal, and re-mapping (or swapping) the ECU (and a few other things)
- BMW didn’t bother bringing the infamous CSL model over to the U.S as it would be too expensive to produce (carbon-fiber roof, emissions certify the CSL engine, etc) and too expensive to sell (it would be a $22k option at the minimum, like it is in Europe). Also, the V8 M3 was just around the corner. The solution? Offer a $4000 Competition package (ZCP) that gave U.S buyers the CSL “look”, as well as the CSL brakes and steering rack
- The “look” referred to the 19″ “CSL style” wheels, aluminum interior trim, alcantara hand brake, and alcantara steering wheel with M Track Mode button replacing the cruise control/audio buttons
- The CSL brakes refer to the enlarged cross drilled/vented two-piece rotors that are fixed onto a “hat”. This setup (common in racing) is lighter, eliminates deformation, and prolongs the life of the wheel bearings. This marks the first time cross-drilled rotors are fitted to a production BMW in the U.S
- In regards to the CSL steering, the rack features a quicker 14.5:1 ratio (only requires 2.7 turns lock-to-lock versus 3.0 on the base M3)
Key Model Year Changes:
Specs:
2001 |
2002 |
2003 |
2004 |
2005 |
2006 |
Specs:
3.2L Inline 6 (S54) | 6spd manual (Getrag) |
333 hp @ 7900 RPM | 262 lb/ft torque @ 4200 RPM |
0-60 MPH: 4.6 seconds | Top Speed: 155 MPH |
Base Price in 2005: | $48,995 |
